Bücker SK25 Aircraft Blueprints & Construction Drawings
This collection includes 116 original blueprints covering the Bücker SK 25, the Swedish-licensed version of the Bücker Bü 181 B-1 Bestmann.
The drawings document the aircraft’s major assemblies and systems in detail — including fuselage, wings, tail, powerplant, cockpit, and technical installations.
All captions and annotations are in Swedish.
(download PDF – 128 pages)
Breakdown as follows:
• Assembly Overview (Översiktsritningar): 3 blueprints
• Fuselage (Kropp ): 26 blueprints
• Wings (Vingar ): 15 blueprints
• Tail Assembly (Stjärt): 16 blueprints
• Powerplant (Motordrivning): 5 blueprints
• Propeller (Propeller): 8 blueprints
• Landing Gear (Landningsställ): 10 blueprints
• Systems (System): 14 blueprints
• Cockpit (Kabine): 12 blueprints
Manufacturing Documents (Tillverkningsdokument): 7 blueprints
